Specifications
Technology Features
- LCD Color Touch Screen with touch pen
- Shows 260,000 colors
- Measures 7" diagonally
- Clock and Date
- Enhanced Stadium Lighting for brighter true color LED lighting of 10" around the needle
- Digital Dual-Feed System ensures utmost fabric control when feeding layers or difficult fabric types
Key Quilting and Sewing Features
- 573 Built-in stitches including
- 137 Utility with 14 one-step buttonhole styles
- 283 Decorative
- 20 Satin
- 61 Decorative satin
- 14 Cross
- 58 Combinable Utility stitches
- 5 Built-in alphabets
- Maximum utility stitch width: 7mm
- Stitch length 0.0mm - 5.0mm
- Digital Dual-Feed System ensures all layers feed evenly
- NeverMiss™ needle threader
- Automatic thread cutter
- Independent bobbin winder motor and Quick-Set, top-loading bobbin
- Advanced Pivoting Feature
- Automatic Fabric Sensor System adjusts presser foot pressure and tension to deliver perfect stitch
- Ergonomic hands-free presser foot lift with extra high setting 10mm automatic and 13mm manual
- 11.25" Workspace to the right of the needle
- Sewing speed up to 1,050 spm
- Automatic drop feed
Convenient Machine Features
- Convenient one-touch buttons for
- Start/Stop
- Reverse sewing
- Reinforcement stitch
- Needle up/down
- Thread cutter
- Automatic presser foot lift
- Auto threading
- Quick-Set bobbin winder
- Needle plate with scale in inches and centimeters
- Additional seam markings on bobbin cover for needle position preference
- Optional quilting extension table for larger work area
- Free arm
- Two accessory storage compartments
Advanced Machine Features
- 2 USB drives: 1 (Type A) drive, connects with a mouse and flash drives and 1 (Type B) USB direct connect to a PC
- Utility stitch editing capabilities
- Store personal stitch settings for each Utility stitch on machine
- Decorative stitch editing capabilities
- Back to the Beginning key, returns to the beginning of a decorative stitch pattern
- Edit and combine Character/ Decorative stitches
- 24 Memory Pockets for Character/ Decorative stitches equaling 1 MG
- Store additional stitch combinations on your PC using the 2 USB ports
- Mirror-image capability for stitches
- Lock key for stitches keeps current settings
- Variable needle positions
- Programmable needle up/down
- Upper and lower thread sensors to alert when threads are broken
- Lateral and diagonal feeding
- Fully automatic built-in darning
- Twin needle settings
Additional Information
- Language conversion capabilities (13 languages)
- Warranty (25-year limited, 10-year parts, 5-year computer circuit, 5-year electrical, 1-year labor)
- Optional Gold Standard Comprehensive Care Program
Instructional and Help Resources
- Built-in Operational Guide
- Built-in Help Messages
- Built-in Sewing Application Guide
Warranty
- 25-year limited
- 10-year parts
- 5-year computer circuit
- 5-year electrical
- 1-year labor
