Specifications
Technical Features
- 16” workspace x 8-1/4” high
- 28 Integrated high-intensity LED light ring illuminating quilting area
- 1/4" Interchangeable Hopping Foot
- Holds the fabric in place while the needle completes the stitch
- Hopping foot stroke/lift - 5mm
- Compatible with standard 1/4" thick rulers and templates
- Maximum sewing speed of 1,800 spm
- Manual Stitch Mode allows manual operation of the machine by selecting one of the two customizable pre-selected needle speeds.
- Stitch Regulator is built-in and regulates your selected stitch length from 4 to 18 stitches per inch.
- Precision Stitch regulated mode follows your lead and is best for ruler work and tracing patterns.
- Cruise Stitch regulated mode allows the needle to immediately begin stitching at the percent speed chosen.
- Included Front and Optional Back Handles for easy control and less fatigue.
- Provides control from two sides of the machine
- Easy-to-reach rubber grips for comfort
- Handle Bar Control Buttons at your fingertips
- Needle Up/Down
- Start/Stop
- Speed Up
- Speed Down
- Color LCD touch screen shows:
- LED lighting options
- Stitch counters
- Diagnostics
- Calculator
- Timers
- Hardware and Software info
- Stitch regulated and manual modes
- Programmable Needle Positioning: Needle Up/Down
- Needle bar stroke - 35.3mm
- Uses Needle System 134, slight ballpoint needle
- Change needles easily with large needle thumb screw
- High-speed rotary hook
- Large capacity “M” class bobbin
- Integrated USB Ports
- External electric bobbin winder with variable speeds
- Adjustable tensions for any type of thread: cotton, polyester, rayon, metallics, holographic
- Thread antenna accommodates guiding thread from larger thread spools
- Two timers
- Reminder timer can be set to sound alarm after a period of time.
- Project timer tracks time spent stitching on a quilt project
- Can use patterns, stencils, threads, 1/4” thick rulers and templates that commercial quilters use
Additional Information
- 4 Languages (English, Spanish, French, German)
- Solid cast aluminum construction
- Internal brushless DC motor
- Machine weight - 43.4 lbs. • Made in U.S.A. of globally sourced parts
- Ask your Baby Lock Retailer about machine maintenance programs.
Warranty
- 10-year limited manufacturer’s warranty
- 5-year parts
- 5-year computer
- 5-year electrical
- 90-day labor
