Specifications
Technology Features
- 20" wide workspace to right of needle 9" high
- Needle Beam
- 7"color touchscreen (add the Pro-Stitcher® and use that tablet for your machine display instead)
- Lighting LED Menu-controlled Lighting for on/off throat space lighting, needle bar lighting, and bobbin light
- Stitch Control features for perfectly-balanced stitches
- 1/4" Interchangeable hopping foot holds down the fabric while the needle completes the stitch
- Manual Stitch Mode allows manual operation of the machine at a pre-selected needle speed
- Stitch Regulator is built-in and regulates your selected stitch length from 4 to 24 stitches per inch
- Precision Stitch regulated mode follows your lead and is best for ruler work and tracing patterns
- Cruise Stitch regulated mode allows the needle to immediately begin stitching at the precent speed chosen
- Quick-Set Tension makes setting upper thread tensions and remembering tension settings easier
- Upper thread break sensor
- Automatic Needle Positioning
- Needle Up/Down
- Full Stitch and Half Stitch - programs the needle to take a half stitch or full stitch when the needle up/down button is pressed
- Basting options in both Cruise and Precision modes allow you to base layers every 1/4", 1/2", 1", 2" or 4"
- Five convenient built-in tie-off stitches for the beginning and end of quilting
- Maximum sewing speed of 2,500 spm
- Save your preferred speed settings with three customizable presets
- Ergonomic front handles are independently adjustable with integrated micro handles for easy control and less fatigue and are programmable
- Easy-to-reach rubber grips for comfort
- Large, color LCD Display shows:
- Stitch Regulator and Manual modes
- Multiple LED Lighting options
- Onscreen hand wheel
- Memory settings
- Needle speed
- Alarm mode
- Calculator
- Timers
- Program settings
- Stitch counters
- Diagnostics
- Low bobbin estimator
- Handle Bar Control Buttons at your fingertips
- Needle Up/Down
- Start/Stop
- Speed Up
- Speed Down
- Front Power Switch for easy access
- Easy needle change with ergonomic thumb screw
- Uses 134R system, slight ball point needle
- High-speed rotary hook
- "M" Class Bobbin
- Low bobbin estimator warns you when you are running low on bobbin thread
- Store three bobbin thread capacity settings based on your preferred thread
- External electric bobbin winder with variable speeds lets you wind your own "M" bobbins with personally selected threads
- Two timers
- Reminder can be set to alarm after a period of time
- Project timer tracks time spent on a quilt project
- Can use patterns, stencils, threads, 1/4" thick rulers and templates that commercial quilters use
Additional Information
- Pro-Stitcher ready - all necessary cabling is pre-installed inside
- 2 USB type A ports
- Thread spool post and thread mast are conveniently placed for easier access
- 4 Languages (English, Spanish, French, German)
- Quiet/smooth operation
- Solid cast-aluminum construction
- Internal DC motor
- Machine weight in box = 88 lbs.
- Designed, engineered, and assembled in the U.S.A.
Warranty
- 10-year casting parts
- 5-year parts
- 5-year circuit boards
- 5-year electrical
- 90-day labor
