Specifications
Technical Features
- Throat space is 18" wide x 8.25" high
- Stitch HarmonyTM built-in stitch regulation
-
Lighting: LED adjustable lighting for the
needle and quilting area
- 28 Integrated high-intensity, natural- color LED lights in a ring illuminating the needle area
- Bright LED light in bobbin area
- Bright LED light strip illuminating the throat space and quilting area
-
1/4" Interchangeable Hopping foot
- Holds the fabric in place while the needle completes the stitch
- Hopping foot stroke/lift - 5mm
- Compatible with standard 1/4" thick rulers and templates
- Maximum sewing speed of 2,200 spm
- Stitch length from 4 to 22 stitches per inch
-
Customizable speed control
- Save your preferred speed settings with two customizable pre-sets
- Increase or decrease “My Speed” by pressing the “+” or “–” buttons
- The needle will take a half stitch or full stitch when the needle up/down button is pressed
- Quick-Set Tension makes adjusting upper thread tension easier as the digital read-out appears on LCD screen
- Basting option allows you to baste layers every .5, .75, 1, 1.5, or 2 seconds
- Responsive foot pedal with half-stitch control
-
User-friendly, adjustable color LCD touch
screen shows:
- LED lighting options
- Stitch counters
- Diagnostics
- Calculator
- Low bobbin warning
- Timer
- Hardware and Software info
- Stitch regulator settings when using Stitch Harmony Stitch Regulator
- Manual stitch settings when using manual mode
- Programmable Needle Positioning: Needle Up/Down
-
Needle bar stroke - 35.3mm
- Uses 134 needle system, slight ball point needle
- Change needles easily with needle clamp screw
- High speed rotary hook
- Large capacity “M” class bobbin
- Low Bobbin Estimator warns you when
you are running low on bobbin thread
- Store three bobbin thread capacity settings based on your preferred thread
- External electric bobbin winder with
variable speeds
- Adjustable tensions for any type of thread: cotton, polyester, rayon, metallics, holographic
- Accommodates larger spools
- Reminder timer can be set to sound an alarm after a period of time
- Project timer tracks time spent on a quilt project
- Smooth table surface assures even flow of quilt
- Easy setup and take-down
Warranty
- 10-year limited manufacturer’s warranty
- 5-year parts
- 5-year computer
- 5-year electrical
- 90 day labor
