Specifications
Technology Features
- WXGA IPS TFT LCD Color Touch Screen Technology
- Mpeg-4 movie/video play function
- IQ Visionary™ Projector
- Projects your embroidery design in a 3" x 5" (7.6 cm x 12.7 cm) area
- Advance and select stitches from projection using the Dual Function Stylus
- Select background color from projection using Dual Function Stylus
- Set width, length and left/right shift
- Projection of Guide Beam, Grid and Needle Beam for precision alignment of stitches
- NeedleCam™ Digital Camera for embroidery and sewing positioning with faster scanning
- Precise Touch Positioning™ using NeedleCam
- Camera detecting buttonhole foot with stabilization plate
- IQ™ Designer with paper holding frame for image scanning
- 2 scanning modes
- Enhanced Stadium Lighting for 13" area of brighter true color LED lighting on the needle and work area with 5 settings
- 2 (Type A) USB 2.0 drives
- SD Card Slot
- Wireless Wi-LAN Function
- Directly download update files to machine
- IQ Intuition™ Monitoring
- IQ Intuition™ Positioning
- Design Database Transfer
- Palette 11 pattern transfer to embroidery and IQ Designer
- NeverMiss™ Automatic Advanced Threading System
- Digital Dual-Feed System
- Advanced Pivoting Feature and Automatic Fabric Sensor System
- Automatic sensors
- Embroidery and sewing speed up to 1,050 spm
- Precise tracking system on embroidery carriage
- Resume mode for Embroidery and IQDesigner
- Programmable shutoff capabilities
- Eco power mode
- Advanced Multi-Function Foot Control
Embroidery Capabilities
- 901 built-in embroidery designs
- 355 Baby Lock exclusives
- 35 Sewlebrity designs
- 15 Buttonhole embroidery designs in 5 sizes
- 15 Buttonhole embroidery frame designs
- 244 Large decorative stitch designs
- 30 Quilting Border Patterns in 3 categories
- 40 Couching patterns
- 5 Large-connect designs
- 10 Motif designs
- 10 Long-stitch designs
- 6 Large applique designs
- 140 Frame combinations
- 38 font styles
- Embroiders up to 10 5/8" x 16" (272mm x 408mm) embroidery field
- 10 5/8" x 16" hoop has new locking mechanism and silicone side grips for slip-free fabric support
- Memory capacity approximately 10MB
- Reads embroidery designs with a stitch capacity of up to 750,000 stitches per design and 127 color changes
- Color Visualizer with favorite color selections
- WXGA IPS TFT Color LCD Touch Screen showing numerous features
- 9-Point trial to check position
- Starting point key for instant alignment of characters or patterns
- Alternate bobbin case for pre-wound bobbins
- Customize embroidery pattern and thumbnail background colors (66 options)
- On-screen grid
- Cuts jump stitches (with on/off capability)
- Embroidery frame clearance setting for easy bobbin changes
- Embroider without removing the foot control
- Compatible with optional W+ Needle Beam Foot and mouse
Embroidery Editing Capabilities
- Combine embroidery designs on screen
- Character/text array function
- Character spacing
- Multi-line text with justification options
- Character insert and group edit capabilities
- Change fonts on letters or words after the design is set
- 0.1°, 1°, 10°, and 90° pattern rotation
- Enhanced design enlargement (up to 200%) and reduction (down to 60%) capabilities
- Design duplication
- Multiple design selection capabilities
- Automatic appliqué
- Automatic basting
- Add automatic stippling, echo stitching, and decorative fill patterns around embroidery designs
- Mirror imaging
- Change color selections within designs
- Enhanced color sorting to optimize sewing order
- Monochrome option for embroidery designs
- Programmable custom thread color selection
- 14 Major thread brands color palettes built-in
Advanced Sewing Capabilities
- 1514 Built-in stitches including
- 184 Utility including 15 one-step buttonhole styles and 1 four-step custom buttonhole
- 527 Decorative
- 79 Decorative satin
- 20 Satin
- 21 Cross
- 63 Combinable Utility stitches
- 3 Hand-look Quilting
- 20 Tapering stitches
- 4 Built-in alphabets
- 40 Quilting stitches offer 57 needle position options
- Stitch length 0.0mm - 5.0mm
- 2 Basting stitch options: Regular 5mm and free-motion
- Maximum Utility stitch width 7mm
- Utility stitch editing capabilities
- 5 Memory settings for each Utility stitch
- Decorative stitch editing capabilities
- Sew Utility and Decorative stitches while embroidery arm is attached
- Specify end-point for stitch line with capability to end with a completed pattern
- Stitch taper for specifying start and end angles of a select category of stitches
- Dual Feed Foot
- Automatic drop feed on screen
- Lock key for Utility and Decorative stitches
- Reinforcement priority settings
- Lateral and diagonal feeding
- Variable needle positions
- Fully automatic built-in darning
- Twin needle settings
Convenience Features:
- Larger sewing bed and workspace with 13.1" to the right of the needle
- Frosted surface finish on machine bed
- Convenient one-touch buttons for
- Start/Stop
- Reverse sewing
- Reinforcement key
- Needle up/down
- Thread cutter
- Automatic presser foot lift
- Automatic needle threading
- Sewing speed control doubles as width control
- Quick-Set, Top-Loading bobbin with sensor
- Quick-Set Independent bobbin winding system
- One finger removable needle plate for easy access cleaning
- Ergonomic 3-position, adjustable knee lift with extra high presser foot lift - 10mm Automatic and 13mm Manual
- Programmable 3-step needle up/down
- Adjustable volume with 5 settings
- Automatic thread cutter (with on/off capability)
- Needle plate with scale in inches and centimeters and additional guideline markings
- Free arm
- Foldable king two-spool thread stand attaches magnetically to machine lid
- Two accessory storage compartments in sewing tray
- Enhanced Accessory Storage Box with 3 interchangeable trays
Instruction and Help Resources
- Built-in Instructions and Reference Manual
- Built-in Operational Guide with up to 40 help topics
- 48 built-in videos
- Built-in Sewing Application Guide
- Built-in Help Messages
- Embroidery Stitch Count System – SCS
- Capability to save settings screen images
Warranty
- 25 years limited
- 10 years parts
- 5 years computer circuit
- 5 years electrical
- 1 year labor
